I Product Features:

1.Small portable, easy to carry;
2.Concise function, simple to operation;
3.Clear image, can be used to judgment pregnant, measuring fat;
4.With probe frequency conversion function, adapted to different inspection demand;
5.Battery can change easy, and for power dissipation is small so battery working time long;
6.Large capacity SD card for store image (optional);
7.With pseudo color display function.

II Specifications:

1.Scanning system: sector sweep;
2.Probe frequency: 3.5MHz/5MHz probe and can variable frequency;
3.Scanning depth: ≥160MM-Screen: 5 inches LED;
4.Display mode: B
5.Image gray scale: 256 level
6.Frame Rate:30 frames/S
7.Image store: 512 frame(by SD card)
8.Measure: distance;
9.Input power: dc 5V (by external battery input)
10.Power consumption: 13W (No charge) /25W (charging)
11.Battery work time: 10 hours
12.Size: 240mm*120mm*45mm
13.Weight: 800g
14.Probe Connector::1

III Standard Configuration:
One Main Host
One 3.5MHz/5.0MHz Mechanical Sector Selectable
One Internal Battery and charger
